Characteristics of the MRC2 series of industrial grade mirror reflection laser rangefinder sensors:

1. Industrial grade mirror reflection laser rangefinder sensor MRC2 series, 300 meter measurement range, Profinet interface, fast measurement speed, high measurement accuracy

2. With a central wavelength of 690nm, the product is not prone to heat generation, and visible light points are visible to the naked eye for precise target positioning

3. Measurement frequency 200Hz, fast response, suitable for measuring moving targets

4. Supports measuring 10m/s (36km/h) moving objects with fast measurement speed

5. High precision, with an accuracy of up to 2mm, truly suitable for industrial sites

6. Standard M12 aviation plug, strong anti-interference ability, complete industrial interfaces, and easy to use

7. Multiple ranging specifications, supporting specifications such as 100m/200m/300m/400m/500m, etc

8. Rich interfaces, supporting interfaces such as RS422/RS485/RS232/SSI/PROFIBUS/PROFINET bus, making it easy to connect various PLC, upper computer, industrial control computer, and other control equipment

9. Metal reinforced shell, sturdy and durable, suitable for complex and harsh industrial environments

10. Widely applicable for online tunnel detection, stacker positioning, driving positioning, industrial kiln car positioning, intelligent logistics, high-level picking truck positioning, AGV obstacle avoidance, ferry damping tire positioning, kiln car distance measurement, steel ladle car positioning in steelmaking plants, electrolytic aluminum crane positioning, electrolytic copper aerial vehicle positioning, industrial equipment weld seam tracking, industrial cable length measurement, steel pipe length measurement, mining steel wire rope length measurement, industrial bar length shear testing, Oil well elevator distance detection, mining car traveling positioning measurement, coking plant overhead crane positioning distance measurement, power plants, steel mills, railways, coal mines, metallurgy, printing, papermaking, food, medical, biopharmaceutical, automotive manufacturing, petrochemical, industrial textile, equipment manufacturing, CNC machine tools, power electronics, shipbuilding, packaging materials, water treatment engineering, environmental protection engineering, and many other industrial scenarios

logistics vehicle AGV obstacle avoidance stacking lidar sensor 100m 200m 300mLogistics warehousing infrared Laser rangefinder
