●Light source: infrared (850nm)
●Visual field: 270°
●Working distance: 0.06m~5m
●Response time: Typical value: 66ms
●Appearance of the detected object: almost
all shapes
●Systematic error: ± 40mm
●Statistical error: ± 30mm
●Zone group: 16 zone groups (each
contains 3 zones) can handle events: 1
zone group

Product Specifications

Detection light source	Wavelength of 905nm, a class of laser products
Maximum detection radius	0.06-5m (white object)	0.06-2m (black object)	Scan the angle range	270°
angular resolution	Barrier avoidance type: 0.5°	Measuremen t type: 0.33	measure ment error	Standard type: ± 4cm
	environmental character istics
ambient temperature	work	-10℃ ~55℃ (frost and fog)
	memory	-40℃~70℃
ambient humidity	work	35％RH~85％R H
	memory	35％RH~95％R H
Anti-light interference	15000Lux
Anti vibration	Frequency: 10Hz~55Hz; amplitude: 0.35 ±	0.05mm; Scan times: three axes, 20 times per axis
shock resistance	Acceleration of 10g; pulse duration: 16	Number of m s: 1000 ± per shaft
electromagnetic compatibility	EMI	EN 61326-1:2013 EN 55011:2009+A1:2010
	EMS	EN 61326-1:2013 EN 61000-4-2:2009 EN 61000-4-3:2006+A1;2008+A2:2010 EN61000-4-4:2012,EN61000-4-6:2009,E N 61000-4-8:2010
Area group switching	Four sets of external input signals (Z1, Z2, Z3, Z4) realize the switching of 16 region groups
levels of protection	IP 65
supply voltage	DC 9V~DC30V	power dissipation		<3W (No load at the output end)
response time	80ms (2 scans) ~640ms (16 scans)
Output mode	BP: obstacle avoidance type, PNP output	BN: obstacle avoidance type, NPN output		DE: Measurement type, Ethernet output
