Model Description:

XT-L301-30, scanning radius 30 meters/frequency 20Hz/scanning 86400 points

XT-L301-40, scanning radius 40 meters/frequency of 25Hz/scanning 108000 points

XT-L301-50, scanning radius 50 meters/frequency 27 Hz/scanning 116640 points

Navigation obstacle avoidance 2D scanning LiDAR product features:

1. The LiDAR warning XT-L301 is suitable for navigation obstacle avoidance and safety protection scenarios, and is widely used for AGV car/robot navigation path planning, collision avoidance, and obstacle avoidance

2. Support intelligent display and warning sound warning, remind drivers, and achieve safe distance prediction

3. The sensing distance can be adjusted up to 50 meters, and different navigation obstacle avoidance distances and areas can be set up

4. Compact size, easy installation, fast response (default detection frequency 27Hz), high sensing accuracy, capable of measuring small columns with a diameter of 3cm

5. Easy to operate, directly connected to 9-28V DC voltage, can achieve alarm

6. Support switch output, equipped with buzzer, sound and light alarm, and clear and clear alarm sound

7. Supports IP65 level protection, dustproof and waterproof, protects equipment, and engineering grade reinforced casing, suitable for complex industrial sites

8. LiDAR triggering, supporting network port output, providing SDK toolkit support for secondary development and other functions

9. Various output interfaces can be customized, with 1 network port+RS422/RS485+switch quantity

10. Widely used: AGV navigation obstacle avoidance, RGV obstacle avoidance, forklift collision warning, gantry height limit warning, intelligent warehouse safety protection, small car collision warning, vehicle collision warning, height limit warning, intrusion warning, perimeter alarm, safety warning, remote sensing switch, pedestrian sensing warning, robot indoor navigation, path planning, contour detection, and security and other fields

30m 40m 50m LiDAR navigation obstacle avoidance scanner AGV car obstacle avoidance path planning Industrial grade LiDAR
